Beidou/GPS/Galileo/GLONASS Series Filter
产品分类
电气规范
| Item | Spec | Unit |
| Center Frequency | 1232 | MHz |
| Band Width | 136 | MHz |
| Insertion Loss | 0.7 | dB |
| Ripple in BW | 0.4 | dB |
| VSWR in BW | 1.5 |
|
| Attenuation | 30dB@103 27dB@1432 | dB |
| Interface Method | SMT |
|
| Size（W*L*H) | 9.2*10.3*4.5 | mm |
| Form | Band Pass |
|
-
